Coconut Belt Dryer/Spray/Vacuum/Fluid Bed /Fluidizing/Spin Flash/Disc/Plate/Paddle/Rotary Drum /Disc /Freezing Vacuum/Drying Machine

Basic Info.

Model NO.	DWT
Grinder	Coconut Grinder
Coconut Processing Machine	Coconut Processing Machine
Vco	Vco Production Line
Machine	Coconut Milk Processing Machine
DC	DC Drying Machine
Coconut	Desiccated Cocount Dryer
Transport Package	Standard Wooden Case
Specification	DWT
Trademark	Yuzhou
Origin	China
HS Code	841939
Production Capacity	100---1000kg

Product Description

Coconut Belt dryer/Spray /Vacuum /Fluid bed /Fluidizing/Spin Flash/Disc/Plate/Paddle/Rotary drum /Disc /Freezing Vacuum/Drying Machine for Vegetable/Fruit/Flavouring/ComdimentDescriptionThis Belt Dryer has single layer,three-layer and five-layer structure, each layer can be independently adjusted the drying temperature according to the characteristics of the materials.The working principle of this multilayer conveyor dryer shows as follows: the material is limit controlled by the hopper and is evenly spread on the mesh belt. The materials are driven by the motor to the top layer, then perform uniform motion in the multilayer belt dryer and conduct downward movement layer by layer. Cold air enters from the two axial flow fans, after ballasting via baffle plate, it will flows from bottom to top. There is equipped with a heater under the mesh belt at each layer. The cold air is constantly gradient heated, and then through the material layer. It will conduct mass transfer and heat transfer with the material layer, so that the moisture contained in the material can be rapidly vaporized and evaporated. When the cold air gets to the top layer, it has become saturated moist air, and will be discharged outdoors under the action of exhaust fan. Material Movement and Process DiagramThis conveyor belt dryer adopts five-layer structure. Materials in the hopper are lifted to the top layer by conveyor belt, and then enter into the drying machine. The materials with the upper belt move to the other end of the multilayer belt dryer, and then slide along the hoop plate down to the next layer. And then the materials along with this layer pass through the conveyor dryer to the other end, and fall to the lowest layer, and so on. The materials along with the lowest belt move to the other end of the drying machine to discharge. Features of Multilayer Belt Dryer1. The hot gas flow passes through the mesh belt and the material layer from bottom to top, thus ensuring uniform heat transfer. This drying machine has high production efficiency and good quality.2. This multilayer conveyor dryer adopts hoisting equipment with uniform feeder, and the thickness of the material layer can be infinitely variable control. Parameters

Model	DWC-20	DWC-25	DWC-32	DWC-36	DWC-48	DWC-60	DWC-80
Spreading Area (m2)	20	25	32	36	48	60	80
Steam Pressure (Mpa)	0.4 to 0.7
Steam Consumption (Kg/h)	150 to 300	180 to 375	240 to 480	270 to 540	360 to 720	450 to 900	600 to 1200
Drying Cycle (min)	20 to 200	60 to 600	100 to 1000
Evaporation Power (Kg/h)	100 to 200	125 to 250	160 to 320	180 to 360	300 to 480	300 to 600	400 to 800
Installed Power (kw)	5.5	5.5	5.5	5.5	14.2	15.2	15.2
Total Weight (Ton.)	8	8	8.5	10	11	13	15
Outline Dimensions (m)	8.9 × 2.4 × 3.4	9.9 × 2.4 × 3.4	11.5 × 2.4 × 3.4	12.5 × 2.4 × 3.4	13.5 × 2.4 × 3.4	14.5 × 2.4 × 3.4	15.5 × 2.4 × 3.4

Yutong Patent

CERTIFICATEPackage:wooden case

Pre-serviceAct as a good adviser and assistant of clients to enable them get rich and generous returns on their investments.1. Introduce the product to the customer in detail, answer the question raised by customer carefully;2.Make plans for choice according to the needs and special requirements of users in different sectors;Sale service1. Ensure product with high quality and pre-commissioning before delivery;2. Delivery on time;3.Provide full set of documents meet customer`s requirements.After-sale serviceProvide considerate services to minimize clients` worries.1.Assist clients to prepare for the first construction scheme;2.Install and debug the equipment;3.Train the first-line operators;4. Examine the equipment;5.Take initiative to eliminate the troubles rapidly;6.Provide technical support;7.Establish long-term and friendly relationship.Service commitment1. Provide clients one-year warranty to make sure the machine work well;2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely;Principle of work matters that should be known before order:1. What is Particle liquid name and materials property, solid contents or water contents, viscosity, surface tension and PH value.2. Powder material contents after the drying, permissible residual water contents, particle size, and permissible maxing temperature. 3. Energy that can be supplied: steam pressure supply capacity, electricity capacity, fuel coal, oil and air capacity?4. Control requirement: how many celcius the inlet air temperature need to be controlled?5. Powder collection requirement: whether or not the bag type collector should be mounted and what is the requirement of the environment for discharging the exhausted gas?6. Other special requirements.
